WS-1000 Horizontal Container Shear

Low investment and Runing Cost
High Production Capacity
Small Space
Electric Motor Drive
Continuous Automatic Working
Cutting Force Range from 400 tons to 1000 tons
Remote Controller Operation
Mobile Type is Optional

EMAIL

Products Description

Dalongkai Container Shears are powerful, versatile and cost effective.  They are a great choice for processing all kinds of HMS such as beams, rails, pipe, re-rod, skeleton plate, tanks and other types of heavy/oversize material. And they’re not as expensive as you might think – especially when compared to the cost of a gantry shear.


Advantages

The advantages of the container shear as compared to common guillotine shears can be summarised as follows

  • Low investment and running costs

  • Loading and picking up of the cut scrap from one material handler, no complicated actions of the material handler

  • Continual loading of the shear in the feed hopper with simultaneous ejection of the cut scrap – no complicated and time-consuming pre-compaction by lids

  • The shears are operated by the material handler operator – no additional operator needed

  • Little space required as compared to vertical gantry shears

  • No assembly and civil foundation costs are needed for operation

  • Thanks to the horizontal cut with largely guided blade carriage there is little wear

  • The forces working on the blade slider always tend towards the center, avoiding twisting forces

  • All inner surfaces have wear plates covered and therefore undergo less wear

  • The scrap is introduced from above, due to the movement of the pre-compressor the scrap automatically slips down and the cut scrap is pushed out of the front

  • Operating experience thanks to over 300 working container shears in China.

  • Ability to process most types of HMS including heavy metal scrap, bulky material, skeleton plate, and rebar.  In addition light and mixed metal scrap can be handled with ease


Technical Specification

Model:

WS-1000
Shear Force:
ton
1000
Pre-compress Force:
ton
200
Blade Length:
mm
1600
Cutting Height:
mm
300/420/500
Motor Power:kw225/275
Supply Power Specificaton:

380V/3Phase, 50Hz
Production Capacity:
tph
15-25
